Description

This is a genuine TRD Performance package for the Vellfire 40 Series Executive Lounge / Z Premier, which includes

[508] GR “Performance Damper®” Set

① Performance Damper FR 1 Qty
② Performance Damper RR 2 Qty
③ Bracket FR (RH/LH) 1 Qty
④ Bracket RR A (RH/LH) 1 Qty
⑤ Bracket RR B (RH/LH) 1 Qty
⑥ Flange bolt A 6 Qty
⑦ Flange nut 6 Qty
⑧ Flange nut B 4 Qty
⑨ Spacer A 4 Qty
⑩ Washer bolt 8 Qty
⑪ Spacer B 4 Qty

Gasoline E-Four – MS303-58014
Gasoline 2WD – MS303-58013

HEV E Four – MS303-58012
HEV 2WD – MS303-58011

[509] GR “Performance Damper®” Set (Interior)

① Performance Damper
② Bracket (RH/LH)
④ Flange Bolt A
③ Flange Bolt A
④ Flange Nut
⑤ Spacer
⑥ Flange Bolt B
⑦ Instruction Manual

GR Door Stabilizer

① Striker
② Plate A
③ Plate B
④ Plate Base
⑤ Torx Bolt (T40)
⑥ Installation and Instruction Manual (this manual)

[510] GR Brace Set

[Front suspension member brace]
3 pieces for hybrid vehicles, two pieces for gasoline vehicles

[Rear suspension member brace]
2 pieces for hybrid vehicles, two pieces for gasoline vehicles

[GR brace]
①Front suspension member brace

(For hybrid vehicles)
②Front suspension member brace

(For hybrid vehicles and gasoline vehicles)
③Rear suspension member brace

(For hybrid vehicles)
④Rear suspension member brace

(For gasoline vehicles)
*The photo of the GR brace installed image (hybrid vehicles and E-Four) is different from the actual vehicle.

*Door stabilizer® is a registered trademark of Aisin Corporation.

GR “Performance Damper®” Set
GR “Performance Damper®” Set (for indoor use)
GR Door Stabilizer & GR Brace Set
