Description

EDFC ACTIVE PRO is a high-spec version of EDFC ACTIVE, which enables automatic adjustment of damping force according to changes in longitudinal G-force and vehicle speed and comes with new and upgraded functions.
Newly added features, such as individual adjustment of 4 shock absorbers, lateral (cornering) G-actuated automatic adjustment, vehicle speed pulse input, and 2 additional input ports to communicate with drivers, are sure to bring out the full potential of each shock absorber as well as the vehicle itself. Please enjoy another dimension of shock absorber performance that EDFC ACTIVE PRO brings. (Patent Pending)
* This product does not adjust vehicle ride height.

Required Kits

Item	Part No.	MSRP excl. Tax	Remarks
Controller Kit	EDK04-Q0349	JPY 59,000
EDFC Motor Kit	EDK05-10100 EDK05-10120 EDK05-10140 EDK05-12120 EDK05-12140 EDK05-14140	JPY 25,500	The matching Motor Kit depends on the vehicle model and shock absorber type. Please use the Compatibility Search.

When installing EDFC Active Pro with shock absorbers that offer separate compression and rebound adjustment, the following items are required.
– EDFC Active Pro Controller Kit x 1
– Motor Kit x 2
– Motor Driver Unit x 2
– Power Supply Cable for Front x 1
– Power Supply Cable for Rear x 1
– Motor Cable x as needed
– EDFC Hex Bolt x 4
– GPS Kit x 1 (for Speed-Reactive Automatic Adjustment Mode and GPS data display)
– Strut Kit x 1 (recommended for strut-type front suspensions)

Optional Items

Item	Part No.	MSRP excl. Tax	Remarks
GPS Kit	EDK07-P8022	JPY 13,900	They are needed if the speed pulse cannot be taken from the vehicle, or if you want all functions to work.
Strut Kit	EDK06-K4474	JPY 9,000	Prevents wiring from entangling with the EDFC motors when the ride height is adjusted. Whether this kit is needed depends on the vehicle. Please consult the Compatibility Search.
Motor Extension Kit	EDK08-P8514-10 EDK08-P8514-12 EDK08-P8514-14	JPY 13,900	If there’s not enough space for adjustment motors, this kit makes it possible to install them regardless. Contains a specially developed ‘flexible shaft’ that allows fitting the EDFC motor a little away from the shock absorber. About the Motor Extension Kit
Piston Rod Top Extension Kit	Made to Order	JPY 13,000	For vehicles in which extension of the piston rod tops ensures enough space around them for the EDFC motors. Produced upon your order. Can also be used in combination with the Motor Extension Kit. About the Piston Rod Extension Kit

Additional Items

Item	Part No.	MSRP excl. Tax	Remarks
Motor Driver Unit	EDC01-P7370	JPY 22,500	The price is per piece. One motor driver unit controls 2 adjustment motors.
Power Cable for Motor Driver Unit	Vehicle Front (2 m) EDC01-P8024	JPY 3,800	The price is per piece. Each additional motor driver unit needs 1 power cable. The front or rear cable applies depending on the location of the motor driver unit.
	Vehicle Rear (5 m) EDC01-P8025
EDFC Motor Cable	EDC01-P8026	JPY 4,800	The price is per piece. For additional motors, or for replacement if a cable is damaged or too short. Over a short distance, the motor drive unit and adjustment motor can be connected without an additional cable.
EDFC Hex Bolt	SAP44-P8463	JPY 900	The price is per piece. Sold in a set of 4. Each additional adjustment motor needs 1 EDFC Hex Bolt.
EDFC Motor	M10: EDC01-K1466-1 M12: EDC01-K1466-2 M14: EDC01-K1466-3	JPY 11,500	Comes with a rubber cover.
Power Supply Filter	EDC01-P8061	JPY 9,000
Signal Converter	EDC01-Q0351	JPY 18,000	Exclusively for EDFC Active Pro. Not compatible with EDFC Active.
8mm Spanner	SST01-F1126	JPY 900
Accessory Kit	EDC02-P8023	JPY 2,600
