Description

Brand M&M HONDA
Series Name FRONT PILLOW UPPER MOUNT
Product Number 00202-FL5-M001
Compatible Car HONDA CIVIC FL5
Product Description
Front pillow upper mount for straight springs with camber angle adjustment function. Comes with a spring seat. For the FK8’s upper mount, which requires strength and high rigidity, we used a large diameter 22φ size pillow ball and used a highly rigid steel material for the mount bracket. Select a direct winding 65φ for the spring. It is a pillow upper mount that matches the Ohlins damper KIT. The diameter of the shaft is 12φ and 1.25 pitch, so it can be installed on other companies’ dampers.

Specifications:
■ Comes with a camber angle adjustment function
■ Comes with a spring seat
■ Uses a large 22φ pillow ball for strength
■ Uses high-rigidity steel material for the mount
■ Uses a 65φ straight-winding spring

Remarks
■Equipped with camber angle adjustment function
■With spring seat
■Using 22φ large-diameter pillow ball considering strength
■Using high-rigidity steel material for mounting
